DQuad Obsession

$145.90 Inc GST

DQuad Obsession



13 in stock

SKU: 2016040 Categories: ,

Description

Dquad Obsession whats that all about?

The Obsession is a Strong X quad what is suitable for indoor/outdoor, race/freestyle, advanced/middle/beginner.

This frame is easy to build and to service when needed. The frame has 4 swappable 4mm carbon arms that are coming together in the middle without any friction. Why not have a unibody that is 2 gram lighter? That’s because we like to give the pilots a opportunity to get up in the air asap and that’s only possible when you have those nice swappable arms. These 4 arms are held together with a 1.5mm carbon bottom plate and a 1.5mm identical Top plate.

Its also possible to build it with the included 1.6mm thick PDB what makes it really nice. The PDB is not one with lots features on it. We like to keep this clean and simple therefore it has only the + and – on it for the esc’s, power connector, and extra’s. On top of the PDB or top plate is enough room to double stack you hardware, like FC, 4in1 esc, VTX, OSD, RX, and so on.

Then we have our 7075 Aircraft Aluminium as a roll cage that has 2 1.5mm carbon side plates that holds the FPV cam in place. A recommended FPV cam for this is a HS1190. On the backside of the roll cage you will find a 2mm carbon VTX antenna mount. This VTX antenna mount is installed in a 45deg angle. If you are doing stunts, races or just having the greatest time of your live in the air and like to capture that in HD than a HD action cam is needed. Action cams are having a hard time to survive on a quad. We have made a 3D Gopro session design in 30 and 40deg what can be fitted directly on top of the roll cage without the need of a strap. Just use 4 screws and you are ready to go. With this nice tide fitted and perfect protected Gopro session cam on your quad you will be able to show all your family and friends your best moments.

What can you expect in a box full of Obsession hardware and the specs of it.

210mm size 5” frame
Frame weight 94 / 95 gram with carbon topplate
4x 4mm carbon arms
2x 1.5mm Carbon bottom/top plate
1x 1.6mm PDB
2x 1.5mm FPV side plate
2x 7075 Aircraft Aluminium roll cage Bracket
1x 2mm VTX antenna mount
1x 3D designed XT60 connector holder
1x Fastener kit incl: bolts, nuts and spacers
1x Battery strap
2x sticker
1x Manual QR code card



Additional information

Weight 0.2 kg
Dimensions 10 × 5 × 4 cm
